Features:
21.8 cu. ft. Capacity
4 Split SpillProtector™ Tempered Glass Shelves
Smart Cooling®
Energy Star® Qualified

CAPACITY
Refrigerator (cu.ft.): 14.5
Freezer (cu.ft.): 7.3
Total (cu.ft.): 21.8

FEATURES
Energy Consumption (kWh/Year): 587
ENERGY STAR® Qualified: Yes

WATER & ICE SYSTEM
Water Dispenser: Yes
Daily Ice Production (lbs): 2.8
IcePlus™ Production (lbs): 3.1
Ice Storage Capacity (lbs): 12.0
Ice System: Factory Installed Ice Maker
Dispenser Light: Yes
Water Filter: LT700P

COOLING
Linear Compressor: Yes
Smart Cooling® System: Yes
Multi-Air Flow: Yes
Temperature Sensors: 4
Evaporator: Yes

CONVENIENCE
Display Type: Membrane / White LED
Temperature Controls: Electronic/Digital
Door Alarm: Yes
Child Lock: Yes
ADA Compliant: Yes
LoDecibel™ Quiet Operation: Yes

REFRIGERATOR
No. of Shelves: 4 Split
Cantilevered Shelves: Hybrid Cantilevered
Shelf Construction: Spill Protector™ Tempered Glass
Crisper Bins: 2 Humidity Crispers
Glide N’ Serve® Drawer: Yes
Refrigerator Light: Ceiling LED

REFRIGERATOR DOOR
No. of Bins: 7 Total (6 Gallon Sized, 1 Half)
Door Bin Construction: 2 Pieces (Clear + Opaque)

FREEZER
Door Type: Pull Drawer
Drawers: 2-Tier Organization
DuraBase™ Solid Drawer Base: Yes
Drawer Divider: Yes
Ice Bin / In Door Ice: Icemaker & Ice bin in the freezer
Freezer Light: Ceiling LED
Freezer Handle: Vista

SmartThinQ®
SmartDiagnosis™: Yes

MATERIALS AND FINISHES
Contour Door: Yes
Hidden Hinges: Yes
Surface: Smooth
Handles: Matching Commercial Handles
Available Colors: Stainless Steel

DIMENSIONS / CLEARANCES / WEIGHTS
Depth with Handles: 35 1/2″
Depth without Handles: 33″
Depth without Door: 29″
Depth (Total with Door Open): 44 3/4″
Height to Top of Case: 67 1/4″
Height to Top of Door Hinge: 68 1/2″
Width: 29 3/4″
Width (Door Open 90° with Handle): 38 1/4″
Width (Door Open 90° without Handle): 33 1/4″
Door Edge Clearance with Handle: 4 1/2″
Door Edge Clearance without Handle: 2″
Installation Clearance: Top 1″, Back 2″
Weight (Unit/Carton): 237 lbs. / 259 lbs.
Carton Dimensions (WxHxD): 31 1/2″ x 69 3/8″ x 37 3/4″

LIMITED WARRANTY
Parts & Labor: 1 Year
Sealed System: 7 Years
Linear Compressor: 10 Years

UPC CODES
UPC: 048231795319
